Acquy HL1.3-12; 12v-1.3ah

Battery Construction & Raw Material

Performance Characteristics

Nominal Voltage …………………………………… 6V

Positive plate………………………………Lead dioxide

Number of cell ………………………………………3

Negative plate…………………………… Lead

Design Life (Solar/wind power) ………………… 5 years

Container………………………………     ABS

Nominal Capacity 77°F(25°C)

Cover……………………………………   ABS

20 hour rate(0.06A,5.25V) …………………………   1.3Ah

Safety valve……………………………     Rubber

10 hour rate(0.11A,5.25V) …………………………   1.1Ah

Terminal………………………………     Copper

5 hour rate (0.21 A,5.25V)…………………………   1.05Ah

Separator………………………………   Fiberglass

1 hour rate(0.78A,4.80V) …………………………… 0.78Ah

Electrolyte………………………………   Sulfuric acid

Internal Resistance

Fully Charged battery 77°F(25°C) …………………60 mΩ

Dimensions and Weight

Self-Discharge

3% of capacity declined per month at 20°C(average)

Length ( mm / inch )……………………………97 / 3.82

Operation Temperature Range

Width ( mm / inch ) …………………………… 24 / 0.94

Discharge ………………………………………… -20~60°C

Height ( mm / inch ) ……………………………52 / 2.05

Charge …………………………………………… -10~60°C

Total Height ( mm / inch )…………………… 57 / 2.24

Storage …………………………………………… -20~60°C

Approx.Weight( Kg / lbs )……………………   0.31 / 0.68

Max.Discharge Current 77°F(25°C)…………… 14.4A(5s)

Short Circuit Current ………………………………18A
